- Model: USW-16-POE
UniFi
Switch 16 is a fully managed Layer 2 switch with (16) Gigabit Ethernet ports
and (2) Gigabit SFP ports.
The
USW-16-POE is a configurable Gigabit Layer 2 switch with sixteen Gigabit
Ethernet ports including eight auto-sensing 802.3at PoE+ ports, and two SFP
ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit
fiber uplink options to your enterprise network. The USW-16-POE features a
1.3" touch LCM to provide status information. With a depth of 7.9",
the compact fanless design can be easily installed in a SOHO rack cabinet.
Managed and
configured by the UniFi Network application with UniFi mobile app support, the
USW-16-POE offers an extensive suite of advanced Layer 2 switching protocols
and features, including operation mode (switching, mirroring, or aggregate) per
port. The UniFi Network application and mobile app allow admins to configure
and monitor virtually all of the switch features in a graphical user interface
from anywhere.
Features:
- (16)
Gigabit Ethernet Ports including (8) 802.3at PoE+ Ports
- (2) 1G SFP
Ports
- 1.3"
touch LCM
- Managed
with UniFi application
Managed
with UniFi Network Application Version: 5.11.27 or higher
Specifications | |
ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
Forwarding Rate | 26.78 Mpps |
Supported Input Voltage Range | 100 to 240VAC |
Switching Capacity | 36 Gbps |
Total Non-Blocking Throughput | 18 Gbps |
Characteristics | The USW-16-POE is a configurable Gigabit Layer 2 switch with sixteen Gigabit Ethernet ports including eight auto-sensing 802.3at PoE+ ports, and two SFP ports. |
Dimensions: | 424.4 x 200 x 43.7 mm (16.71 x 7.87 x 1.72") |
Weight: | 2.80 kg (6.17 lb) |
Operating Temperature: | -5 to 40° C (23 to 104° F) |
Operating Humidity: | 10 to 90% Noncondensing |
Networking Interface: | (16) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports Ethernet In-Band |
Powering | |
PoE | 42W |
Power Supply: | AC/DC, Internal, 60W |
Power Method: | 100-240VAC/50-60 Hz, Universal Input |
Max power consumption: | 18W |
Certification & Approvals | |
Certifications | CE, FCC, IC |
