Ubiquiti UniFi XG (UAP-XG)

Deploy the UniFi XG AP in very high-density environments requiring maximum wireless performance. The UniFi XG AP features simultaneous, dual-band, 4x4 MU-MIMO technology and convenient 802.3bt PoE compatibility.

10G and 1G Ethernet Connectivity Designed to be a 10G Ethernet backhaul, the primary port carries both data and PoE, while the secondary Gigabit Ethernet port is for bridging and also supports PoE input.

Features:

• 10 Gigabit Ethernet Support
• 4x4 MU-MIMO Quad-Radio: (3) client, 1 Security
• Dual 5 GHz 802.11ac Wave 2 Radios
• 3.466 Gbps Combined Radio Rate in 5 GHz
• 800 Mbps Radio Rate in 2.4 GHz
• Dedicated Security Radio with Persistent Threat Management
• 1,500 Client Association Limit

SPECIFICATION

• Operating Frequency 2.4GHz 5GHz
• Dimensions 228 x 228 x 50 mm (8.98 x 8.98 x 1.97")
• Weight 1.35 kg (2.98 lb)
• Interfaces (1) 10/100/1000 Ethernet Port
• (1) 1/10 Gbps ICM Ethernet Port
• Mounting Wall/Ceiling (Kits Included)
• Operating Temperature -10 to 60° C (14 to 140° F)
• Max. TX Power 2.4 GHz - 25 dBm
• 5 GHz - 25 dBm
• Encryption WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11 w/PMF
• Wi-Fi Standards 802.11 a/b/g/n/ac/ac-wave2
• Operating Humidity 3GHz
